Ultrasonic Baths
Robust refrigeration system with metering control provides fast heat removal and stable temperatures. Industrial-grade circulating pumps deliver extra pressure providing more efficient heat exchange, better temperature uniformity, and improved reservoir agitation. Added pump pressure provides greater flexibility where you place the circulator. Long-life, high-wattage heaters deliver fast fluid heat up for applications requiring rapid fluctuations. High-temperature cutoff and low-level fault protect baths from adverse events. Includes inlet/outlet connections for external loop applications.
-
Standard Digital Controller Baths are ideal for routine temperature control. They feature three programmable set points, adjustable high-temperature cutoff, user-settable Min/Max temperature limits, and an adjustable pump nozzle.
-
Advanced Digital Controller Baths offer all the features of the Standard Digital models (except adjustable pump nozzle) plus five programmable set points, a two-stage (force/suction) pump for greater temperature control and circulation capacity, and a USB port.
Product Features
-
Powerful refrigeration system provides excellent heat load removal across range of operating temperatures.
-
Two-speed pump with up to 21 L/min flow.
What's Included:
6-ft (1.8-m) power cord with plug, M16 x 1 connection and adapters for included 8- and 12-mm hose barb fittings with clamps for external connections.
Technical Specifications
-
Capacity: Liters 6
-
Type: Circulators (Cooling/Heating)
-
Min temperature: 20 deg C
-
Max temperature: 100 deg C
-
Dimensions: 8x24.2x16.3
-
Temp sensor: Pt RTD
-
Temp stability: +0.1deg C
-
Cooling capacity: at 20 C 250W
-
Low-level cutoff: no
-
Pressure pump: Max head at 0 flow 4.4 psi (300mbar)
-
Heater wattage: 1.2 kW
-
Pump type: Force
-
Max flow rate: Liters/min 15 L/min
-
Power: VAC 230 Hz 50
